Features of GIYIK ECR series battery chargers
Features of GIYIK ECR series battery chargers:
Output characteristic : Constant voltage and Current limited
Input rate : 220/240V single phase or 380/400V three Phase
Output rate : From 12Vdc to 110Vdc, 5A to 200A
Suitable for battery type : Pocket type Ni-CD cells or VRLA type battery block
Charge mode and Charging output :
Float / Trickle (For battery standby)80% to approx. 135% of V nominal
Boost / Eq (For battery charge up to fully capacity and equalizing)
80% to approx. 145% of V nominal
Output Ripple : 2% P.P
Protection
Mains Input : 2P MCB & Surge Suppressor
Rectifier input : HRC fuses
Rectifier output : 2P DC MCB
Battery Output : HRC fuses
DC voltage dropper device : The diode groups are made up of series-connected silicon diodes, keeping the output voltage within the specified tolerance. The electronic control unit of the dropping diode device is a stand-alone unit.
